Product Details
Place of Origin: China
Brand Name: SENOVA (SEAVOVA)
Certification: CE
Model Number: NeuIncu-214R
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Available upon request
Packaging Details: Plywood case
Delivery Time: Approx. 10 working days
Payment Terms: T/T
Supply Ability: 100 units/month
Humidity Control: |
95% Relative Humidity |
Temperature Range: |
3°C Above Ambient To 60°C |
Co2 Sensor Type: |
Infrared (IR) Sensor |
Heating Method: |
Air-jacketed PID Control |
Warranty: |
1 Year |
Alarm System: |
Audible And Visual Alarms For Temperature And CO2 Deviations |
Door Type: |
Double-pane Glass Door With Inner Door |
Chamber Volume: |
1750L |
Exterior Dimensions: |
516x543mmx636 (WxDxH,mm) |
Humidity Method: |
Natural Vaporization |
Power Rating: |
700W |
Voltage: |
110V/60Hz Or 220V/50Hz |
Humidity Control: |
95% Relative Humidity |
Temperature Range: |
3°C Above Ambient To 60°C |
Co2 Sensor Type: |
Infrared (IR) Sensor |
Heating Method: |
Air-jacketed PID Control |
Warranty: |
1 Year |
Alarm System: |
Audible And Visual Alarms For Temperature And CO2 Deviations |
Door Type: |
Double-pane Glass Door With Inner Door |
Chamber Volume: |
1750L |
Exterior Dimensions: |
516x543mmx636 (WxDxH,mm) |
Humidity Method: |
Natural Vaporization |
Power Rating: |
700W |
Voltage: |
110V/60Hz Or 220V/50Hz |
|
Model |
ST-214R |
|
Control |
PID |
|
Display |
7”color LCD touch screen |
|
Heating |
Air jacket, 6-side heating |
|
Sterilization |
90℃ high-temperature moist heat |
|
Capacity |
175L |
|
Shelf size |
480x478mm |
|
Shelf Qty. |
3PCS |
|
Refrigerant |
R134a |
|
Temperature Control Range |
RT+3℃ to 60℃ |
|
Temperature Control Accuracy |
±0.1℃ |
|
Temperature Uniformity |
±0.3℃(@ 37℃) |
|
CO2 Sensor |
IR |
|
CO2 Control Range |
0-20% |
|
CO2 Control Accuracy |
±0.1% |
|
CO2 Uniformity |
±0.5%(@ 5%) |
|
Humidifying Method |
Natural evaporation via bottom water pan |
|
Humidity Control Range |
95% RH |
|
N.W.(Kg)/G.W.(Kg) |
100/120 |
|
Chamber Dimensions |
680x685x900 (WxDxH,mm) |
|
Overall Dimensions |
516x543mmx636 (WxDxH,mm) |
|
Packing Size |
60x65x80 ( LxWxH,cm) |
|
Power (W) |
700 |
|
Power Supply |
AC 220V±10%/50Hz or 60Hz. Optional: AC110V±10%/60Hz |
Essential for modern bioscience, the CO2 incubator creates and maintains a physiologically consistent atmosphere for cultivating living cells and tissues. Its core function lies in regulating three critical parameters: temperature, humidity, and CO2 levels. The addition of CO2 is not merely for atmosphere; it serves as a vital pH stabilizer by reacting with water in the culture medium to create a bicarbonate buffer system.
Modern devices achieve exceptional precision using infrared sensors for gas measurement and ensure chamber-wide uniformity through gentle air circulation. A major focus is preventing microbial contamination, addressed via sealed designs, HEPA-filtered air, and dry-heat sterilization at temperatures up to 180°C. Consequently, this equipment is a cornerstone in applications ranging from basic cell culture and microbiology to specialized domains like VIF, tissue engineering and immunology,in the field of life science, where uncontaminated, stable growth conditions are non-negotiable.
