SENOVA BIOTECH (SHANGHAI) CO., LTD.
Product Details
Place of Origin: China
Brand Name: Senova
Certification: CE
Model Number: HG-760D
Payment & Shipping Terms
Minimum Order Quantity: 1 unit
Price: Available upon request
Packaging Details: plywood case
Delivery Time: 5-20 working days
Payment Terms: T/T
Supply Ability: 200 units
Product Name: |
Pharmaceutical Glassware Washer |
Capacity: |
760L |
Drying Temperature: |
RT-120℃ |
Tank Internal Temprature: |
RT - 93℃ |
Control System: |
PLC With 12" Touch Screen |
Door Opening: |
Electric |
Door Structure: |
Double Doors |
Power Supply: |
220V/50Hz |
Product Name: |
Pharmaceutical Glassware Washer |
Capacity: |
760L |
Drying Temperature: |
RT-120℃ |
Tank Internal Temprature: |
RT - 93℃ |
Control System: |
PLC With 12" Touch Screen |
Door Opening: |
Electric |
Door Structure: |
Double Doors |
Power Supply: |
220V/50Hz |
Dual spray arms for full coverage and specialized racks to maintain water pressure integrity across multiple tiers. Two standard water inlets allow for connection to different sources.
The user interface is an intuitive LCD touch screen, complemented by an emergency stop switch.
Process repeatability is supported by automated detergent injection and the fine-tuned hydraulic performance of a premium circulating pump and flow meter.
Industrial PLC for reliability, accessible via a vibrant touch screen.
A vast array of storable and nameable program slots.
The system includes diagnostic self-tests, is housed to resist environmental factors, and preserves program status during power interruptions.
Multiple protocols: immediate shutdown capability, continuous leak sensing, and an automatic door safety device to avoid crushing or impact.
The door is securely locked during operation.
Electrical safety is reinforced by isolating high and low voltage systems in separate, lockable boxes.
The washer also features an extensive alarm system for critical operational parameters.
Three-level password control.
More than 20000 cleaning records and over 20000 alarm records.
These logs can be reviewed on the device screen, exported to a USB flash drive in a universal PDF format, or sent to an optional printer.
Each cleaning record is exhaustive, and the system’s background logging of all activities ensures full accountability and traceability.
| Model | HG-760D |
| Exterior Dimension(W*D*H,mm) | 1800*1000*2250 |
| Capacity(L) | 760 |
| Control System | PLC/Siemens or equivalent |
| Display | 12" touch screen |
| Door Structure | Double doors |
| Door Opening Method | Electric door(manual door optional) |
| Circulating pump flowA(L/min) | 800 |
| Circulating pump flowB(L/min) | 800 |
| Tank Internal Temperature(C) | Rt-93 |
| Water Heater Power(kW) | 1 |
| Drying temperature(C) | Rt-120 |
| Dry Power(kW) | 6 |
| Voltage(V/Hz) | 380/50 |
Customization for Complex Lab Needs
The one-size-fits-all approach is obsolete in modern labs. Recognizing this, today's laboratory glassware washers offer extensive customization to suit diverse research requirements. While early models offered basic functions, current systems provide a wide array of programmable protocols for different soil types, glassware shapes, and contamination levels. Gentle washing motions protect delicate instruments, while powerful jets tackle tough residues. This flexibility is complemented by seamless integration with a lab's existing water purification infrastructure. Whether a lab requires simple rinsing or validated sterilization cycles, modern washers can be tailored to the task. This adaptable, application-specific design, championed by companies like Senova, ensures the equipment meets the exacting standards of any research facility.
